SS94A1
Inventory: 125
$21.56Details
| Tech Specifications | |
| Description | Product Attribute |
| Manufacturer | Honeywell |
| Product Category | Board Mount Hall Effect / Magnetic Sensors |
| Type | Position Sensor |
| Operating Supply Current | 30 mA |
| Maximum Output Current | 1 mA |
| Operating Point Min/Max | - 500 G to 500 G |
| Operating Supply Voltage | 12 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Mounting Style | Through Hole |
| Package / Case | SIP-3 |
| Packaging | Bulk |
| Output Voltage | 4 V |
| Product Type | Board Mount Hall Effect / Magnetic Sensors |
| Subcategory | Sensors |
| Supply Voltage - Max | 12.6 V |
| Supply Voltage - Min | 6.6 V |
