KSPS Ultra-high precision gauge pressure transmitter
DESCRIPTION ：
A member of the KSP product family, the KSPS is a high precision pressure transmitter with advanced sensor technology. By combining absolute pressure with static pressure and temperature compensation on the sensor chip, KSPS can provide high measurement accuracy and stability over a wide range of static pressure and temperature, with a maximum accuracy of 0.05%. Tested to metrology standards to provide the highest level of compatibility assurance and integration capabilities.
CHARACTERISTICS：
1、316L stainless steel isolation diaphragm structure
2、High precision, all stainless steel structure
3、Small size and light weight
4、Strong anti-interference and long-term stability
5、Diversified structure, easy to install and use
6、Wide measuring range, can measure absolute pressure gauge pressure and sealing reference pressure
7、Vibration and impact resistance
8、Zero, full range adjustable
PERFORMANCE
| Scale range | -100kPa…0～10kPa…21MPa |
| Accuracy | 0.05% |
| Power supply | 8~36VDC |
| Pressure type | Gauge, Absolute, Sealed |
| Power supply output | 4～20mA |
| Response time | ≤1ms (rise to 90%FS) |
| Overload pressure | 150%FS（≤21MPa） |
| Service life | ≥10×10^6 pressure cycle |
| Operating temperature | -40℃～80℃ |
| Calibration temperature | -20℃～60℃（customizable） |
| Temperature of medium | -20℃～80℃ |
| Temperature of storage | -40℃～125℃ |
| EMC- Interference | IEC 61000-6-3 |
| EMC- Disturbance rejection | IEC 61000-6-2 |
| Resistance to insulation | ≥100MΩ/500VDC(200MΩ/250VDC) |
| Resistance to vibration | Sine curve :20g,25Hz ~ 2kHz IEC 60068-2-6; Random :7.5g,5Hz ~ 1kHz IEC 60068-2-64; |
| Resistance to impact | Impact: 200g/1ms; IEC60068-2-27; Free fall: 1m; IEC60068-2-32 |
| Class of protection | IP65 |
| Medium compatible | Compatible with various media of 316L stainless steel |
| Weight | 150～180g |
| Six square size | HEX27 |
